C2300 - Swing Door System
The C2300 is a sophisticated aluminum swing door system featuring a hinged design with a frame depth of 1-5⁄8″ (40mm) and reduced profile thickness. Constructed from premium 6063 T-5 aluminum extrusions – an architectural-grade alloy known for exceptional strength, durability, and superior surface finish quality – this system is engineered for both residential and commercial applications. It delivers exceptional performance while maintaining an elegant aesthetic profile.
Opening Configurations
Inward Opening Options:
Side hung (traditional swing)
Tilt & turn functionality
Parallel sliding operation
Bottom hung configuration
Outward Opening Options:
Side hung operation
Top hung projection
Pivoting on horizontal or vertical axis
Hardware & Security Features
Security hardware options available
Concealed hinges for clean aesthetics and enhanced security
Compatible with various locking mechanisms
Design Versatility
Sash profiles: Available in straight or curved configurations
Bead options: Straight or curved glazing beads for custom aesthetics
Dual color systems: Frame and sash can be finished in different colors
Finish Options
Powder coating: RAL colors, mottled, and textured finishes (>60 microns, Qualicoat standard)
Wood effect: Authentic wood-grain powder coating (Qualideco standard)
Anodized: Class 15 standard (Class 20 and 25 available on request)
Anti-bacterial coating: Available for hygienic environments
Construction Materials
Alloy: Premium 6063 T-5 aluminum extrusion for superior durability and corrosion resistance
6063 is a high-strength architectural grade aluminum alloy known for its excellent extrudability and surface finish quality
T-5 temper designation indicates the alloy is artificially aged to achieve optimal strength and workability
This combination provides exceptional dimensional stability, corrosion resistance, and weldability
Ideal for precision machining and anodizing processes, ensuring consistent quality and finish
Engineered for long-term performance in various environmental conditions
Applications
The C2300 door system is ideal for:
High-end residential projects
Commercial buildings requiring style and performance
Projects demanding superior weather resistance
Applications where acoustic control is essential
Designs requiring flexible opening configurations
Note: Always consult technical drawings and specifications for specific typologies, dimensions, and weight limitations before installation.
Frame Profile
- Frame depth: 1-5⁄8″ (40mm) with reduced profile thickness
- Sightlines: Frame 1-5⁄8″ (40mm), Sash 1-7⁄8″ (48mm) for clean, contemporary appearance
- Profile thickness: 0.055″ (1.4mm) for doors
- Glazing accommodation: 5⁄32″ (4mm) minimum to 1-1⁄32″ (26mm) maximum thickness
Dimensions & Capacity
- Maximum sash dimensions: Width 59-1⁄8″ (1,500mm) × Height 94-1⁄2″ (2,400mm)
- Maximum sash weight: 265 lbs (120kg)
- Note: Consult us for maximum weight and dimensions according to specific typologies
Performance Standards
Thermal transmittance: Uw ≥ 0.35 BTU/hr·ft²·°F (2.0 W/m²K ) for enhanced energy efficiency
Acoustic insulation: Up to 39 dB for superior sound dampening
Air permeability: Class 4 (EN 12207) – exceptional weather sealing
Water tightness: Class 9A (EN 12208) – superior water resistance
Wind resistance: Class C5 (EN 12210) – outstanding structural stability
