C Millennium 2000

AUTOMATIC DOOR SYSTEM

Thermal insulation Uf

Uw from 2,3 (W/m²K)

Resistance to mild impact

(EN 13049:2003) CLASS 5 (Max)

Coplanar door entry system with frame depth of 45 mm for commercial and residential buildings

Share on facebook
Facebook
Share on pinterest
Pinterest
Share on linkedin
LinkedIn

Specification

  • Key features
  • Technical Specifications
  • Performance
» Available in 2 versions:

- Millenium 2000 door: with double or triple flag hinges of high strenght, capable of supporting up to 180 kg. per sash.

- Millenium 2000 automatic door: This new solution optimizes the room's space, it has been specifically designed to resolve crowded entrances (offices, shopping centres, hospitals…) as it guarantees good pedestrian circulation as well as security in emergency situations.


» Possibility of 1 or 2 sashes, with or without fixed areas, it comes with the optionof automatic opening, using two different motor positions; one at 12 cm. high and another being minimalist at only 7 cm high.


» Possibility of incorporating a motorization system.

» Maximum glazing thickness

30 mm


» Opening possibilities

Open inwards: 1 & 2 sashes
Open outwards: 1 & 2 sashes
Swing opening: 1 & 2 sashes
Automatic opening: sliding of 1 & 2 sashes. Side hung in and out of 1 sash.


» Profile thickness

Door 2,0 mm


» Maximum dimensions/sash

Width  (L) = 1.450 mm
Height (H) = 3.000 mm Side hung door
Width  (L) = 2.000 mm
Height (H)= 3.000 mm Automatic sliding door
Width  (L) = 1.100 mm
Height (H) = 3.000 mm Swing door


» Maximum weight/sash

190 Kg
120 Kg automatic version


Please consult regarding maximum weight and dimensions according to types

»
Finished

Color powder coating (RAL, mottled and rough)
Wood effect powder coating
Anti-bacterial powder coating
Anodized
Resistance to mild impact
(EN 13049:2003) CLASS 5 (Max)
Watertightness
Wind load resistance
Thermal insulation (Uf)
Uw from 2,3 (W/m²K)
Maximum acoustic insulation
Rw=38 dB

Photos

We offer high variety of Aluminum windows and doors. Every order is custom made according to our customers requirements. Our modern construction solutions make it possible to create extremely large g lazed areas and improve building design and interior décor not available with most of our competitors, for example 25’ W x 9’H lift and slide doors. We have almost an unlimited potential in terms of both colors and their different shades for our aluminium components. Another key benefit for our products are the components utilizing multi point locking. This is achieved through a link gear running around the window sash, which operates pins which in turn lock into keepers located around the perimeter of the sash opening. Depending on the size of sash used, there can be up to twelve locking points on any one sash. In doors a six-point lock is used. This comprises of four compression roller pins, one latch and one dead bolt. All the locks on any one sash are operated by one lever and secured by one key. Further this creates insulating advantage as an even sash seal is achieved as well as enhanced security. Pleae note we can perform the installation or assit our customer in an installation consult capacity.
