Window and door sliding systems
Minimalistic frame sliding system which allows to have the maximum luminosity with the minimum visible section of aluminum, and makes possible to cover great openings with a glass surface of 94%. Its extraordinary glazing capacity allows to place glasses of up to 2 1/8” mm thickness which guarantees the best acoustic and thermal performance in a system with these characteristics. It is available in configurations of fixed + panel, 2 and 4 panels, and the maximum dimensions are over 13’ per panel width. It has a visible section of just 1” and the possibility to inlay totally the bottom, lateral and top frames. It counts with the possibility of motorized opening for weights up to 1543 lbs, and manual opening for up to 882 lbs.
Additionally, it allows to place multipoint lock systems by operating rod, with or without key. The rollers are placed in the frame, and the sashes are with a stainless steel reinforced channel which makes the sliding movement smoother.
|Double track depth|
Triple track depth "
|Glazing range||frame: up to 4,5 - 7 in (3 ralls)|
|sash: up to 1,5|
|Maximum size (H×W)||H to|
157 1/2W to
|Max weight lbs||882|
(EN 12207:2000) CLASS 4
(EN 12208:2000) CLASS 7A* / 9A**
|Wind load resistance||
(EN 12210:2000) CLASS C3* / C4**
|Thermal insulation (Uf)||
from 0,9 (W/m²K)
|Maximum acoustic insulation||
